Linear Optimization

# Import necessary libraries
import numpy as np
import matplotlib.pyplot as plt
import sympy as sp
from mpl_toolkits.mplot3d import Axes3D
from matplotlib import cm
from IPython.display import display, Math

1. Introduction to Optimization

Optimization is the process of finding the best solution to a problem from a set of possible solutions. In mathematical terms, we seek to find the minimum or maximum of a function $f: \mathbb{R}^n \rightarrow \mathbb{R}$.

Key Concepts:

Objective Function: The function $f(x)$ we want to minimize or maximize
Decision Variables: The variables $x = (x_1, x_2, …, x_n)$ we can control
Optimal Solution: The point $x^{\ast}$ where $f(x^{\ast})$ is minimal (or maximal)

Types of Optimization:

Unconstrained Optimization: Find $\min_{x \in \mathbb{R}^n} f(x)$
Constrained Optimization: Find $\min_{x \in \mathbb{R}^n} f(x)$ subject to constraints $g_i(x) \leq 0$, $h_j(x) = 0$

1. Mathematical Foundations

Gradient

The gradient of a function $f: \mathbb{R}^n \rightarrow \mathbb{R}$ at a point $x$ is the vector of partial derivatives:

$$\nabla f(x) = \left[\frac{\partial f}{\partial x_1}, \frac{\partial f}{\partial x_2}, …, \frac{\partial f}{\partial x_n}\right]^T$$

Intuition: The gradient points in the direction of steepest increase of the function. Its negative points in the direction of steepest decrease.

Hessian Matrix

The Hessian matrix is the matrix of second-order partial derivatives:

$$H(x) = \begin{bmatrix} \frac{\partial^2 f}{\partial x_1^2} & \frac{\partial^2 f}{\partial x_1 \partial x_2} & \cdots & \frac{\partial^2 f}{\partial x_1 \partial x_n} \\ \frac{\partial^2 f}{\partial x_2 \partial x_1} & \frac{\partial^2 f}{\partial x_2^2} & \cdots & \frac{\partial^2 f}{\partial x_2 \partial x_n} \\ \vdots & \vdots & \ddots & \vdots \\ \frac{\partial^2 f}{\partial x_n \partial x_1} & \frac{\partial^2 f}{\partial x_n \partial x_2} & \cdots & \frac{\partial^2 f}{\partial x_n^2} \end{bmatrix}$$

Intuition: The Hessian describes the curvature of the function, helping us determine whether a point is a minimum, maximum, or saddle point.

2. Stationary Point Analysis

A stationary point (or critical point) is a point where the gradient equals zero:

$$\nabla f(x^*) = 0$$

Classification of Stationary Points

Using the Hessian matrix $H(x^*)$ at a stationary point:

Local Minimum: $H(x^*)$ is positive definite (all eigenvalues > 0)
Local Maximum: $H(x^*)$ is negative definite (all eigenvalues < 0)
Saddle Point: $H(x^*)$ has both positive and negative eigenvalues
Inconclusive: $H(x^*)$ is singular or has zero eigenvalues

Implementation

# Define symbols for symbolic computation
x, y = sp.symbols('x y')

# Example function: f(x,y) = x^2 + y^2
f_symbolic = x**2 + y**2
print("Function: f(x,y) =", f_symbolic)

# Compute gradient symbolically
gradient = [sp.diff(f_symbolic, x), sp.diff(f_symbolic, y)]
print("\nGradient: ∇f =", gradient)

# Solve for stationary points
stationary_points = sp.solve(gradient, (x, y), dict=True)
print("\nStationary Points:", stationary_points)

# Compute and display Hessian matrix
Hessian = [[sp.diff(f_symbolic, x, x), sp.diff(f_symbolic, x, y)],
           [sp.diff(f_symbolic, y, x), sp.diff(f_symbolic, y, y)]]
print("\nHessian Matrix:")
display(Math(sp.latex(sp.Matrix(Hessian))))

# Classify each stationary point
for point in stationary_points:
    # Evaluate Hessian at the point
    H_eval = [[expr.subs(point) for expr in row] for row in Hessian]
    H_matrix = sp.Matrix(H_eval)

    # Calculate eigenvalues
    eigenvalues = list(H_matrix.eigenvals().keys())
    eigenvalues_float = [float(sp.N(ev, chop=True)) for ev in eigenvalues]

    # Classify based on eigenvalues
    if all(ev > 0 for ev in eigenvalues_float):
        classification = "Local Minimum (convex)"
    elif all(ev < 0 for ev in eigenvalues_float):
        classification = "Local Maximum (concave)"
    elif any(ev > 0 for ev in eigenvalues_float) and any(ev < 0 for ev in eigenvalues_float):
        classification = "Saddle Point"
    else:
        classification = "Inconclusive"

    print(f"\nPoint {point}:")
    print(f"Classification: {classification}")
    print(f"Eigenvalues: {eigenvalues_float}")

Output:

Function: f(x,y) = x**2 + y**2

Gradient: ∇f = [2*x, 2*y]

Stationary Points: [{x: 0, y: 0}]

Hessian Matrix:


<IPython.core.display.Math object>


Point {x: 0, y: 0}:
Classification: Local Minimum (convex)
Eigenvalues: [2.0]

3. Gradient Descent Algorithm

Gradient Descent is an iterative optimization algorithm for finding a local minimum of a differentiable function.

Formal Definition

Let $f: \mathbb{R}^n \rightarrow \mathbb{R}$ be a continuously differentiable function. The gradient descent algorithm generates a sequence ${x_k}_{k=0}^{\infty}$ according to the iteration:

$$x_{k+1} = x_k - \alpha_k \nabla f(x_k)$$

where:

$x_0 \in \mathbb{R}^n$ is the initial point
$\alpha_k > 0$ is the step size (or learning rate) at iteration $k$
$\nabla f(x_k) \in \mathbb{R}^n$ is the gradient of $f$ evaluated at $x_k$

Motivation

The gradient descent algorithm is based on the first-order Taylor approximation:

$$f(x + \Delta x) \approx f(x) + \nabla f(x)^T \Delta x$$

To minimize $f$, we want to choose $\Delta x$ such that $f(x + \Delta x) < f(x)$. The direction of steepest descent is:

$$\Delta x = -\alpha \nabla f(x)$$

for some $\alpha > 0$. This gives us the maximum decrease in $f$ for small steps.

Finite Difference Approximation

In practice, we often cannot compute $\nabla f$ analytically. We use the finite difference method to approximate partial derivatives:

Forward Difference:

$$\frac{\partial f}{\partial x_i} \approx \frac{f(x + h e_i) - f(x)}{h}$$

Central Difference (more accurate):

$$\frac{\partial f}{\partial x_i} \approx \frac{f(x + h e_i) - f(x - h e_i)}{2h}$$

where:

$h > 0$ is a small step size (typically $h \in [10^{-8}, 10^{-4}]$)
$e_i$ is the $i$-th standard basis vector

Learning Rate Properties

The choice of learning rate $\alpha_k$ is crucial:

Constant Learning Rate: $\alpha_k = \alpha$ for all $k$
- Simple but may not converge or converge slowly
Diminishing Learning Rate: $\alpha_k \rightarrow 0$ as $k \rightarrow \infty$
- Ensures convergence under certain conditions
- Example: $\alpha_k = \frac{\alpha_0}{1 + \beta k}$
Adaptive Learning Rate: Based on local properties of $f$
- Line search methods
- Trust region methods

Stopping Criteria

Common criteria for terminating the algorithm:

Gradient norm: $|\nabla f(x_k)| < \varepsilon$
Relative change in function value: $\frac{|f(x_{k+1}) - f(x_k)|}{|f(x_k)|} < \varepsilon$
Relative change in parameters: $\frac{|x_{k+1} - x_k|}{|x_k|} < \varepsilon$
Maximum iterations: $k \geq k_{\max}$

Challenges and Limitations

Local Minima: Gradient descent only guarantees convergence to local minima
Saddle Points: Can get stuck or slow down significantly
Ill-Conditioning: Poor performance when Hessian has large condition number
Step Size Selection: Too large → divergence; Too small → slow convergence

def numerical_gradient(f, point, h=1e-4):
    """
    Compute numerical gradient using finite differences.

    Parameters:
    - f: function to differentiate
    - point: point at which to evaluate gradient
    - h: small step for finite difference

    Returns:
    - gradient vector
    """
    grad = np.zeros_like(point)
    for i in range(len(point)):
        point_minus = np.copy(point)
        point_plus = np.copy(point)
        point_minus[i] -= h
        point_plus[i] += h
        grad[i] = (f(point_plus) - f(point_minus)) / (2 * h)
    return grad

def gradient_descent(f, start_point, learning_rate=0.1, num_steps=100, tolerance=1e-6):
    """
    Perform gradient descent optimization.

    Parameters:
    - f: objective function
    - start_point: initial point
    - learning_rate: step size
    - num_steps: maximum number of iterations
    - tolerance: convergence tolerance

    Returns:
    - final_point: optimized point
    - history: trajectory of points
    """
    point = start_point.copy()
    history = [point.copy()]

    for step in range(num_steps):
        grad = numerical_gradient(f, point)

        # Check convergence
        if np.linalg.norm(grad) < tolerance:
            print(f"Converged after {step} iterations")
            break

        # Update point
        point -= learning_rate * grad
        history.append(point.copy())

    return point, history

# Example: Minimize f(x,y) = x^2 + y^2
f_numpy = lambda p: p[0]**2 + p[1]**2
start_point = np.array([10.0, 10.0])

print("Starting point:", start_point)
print("Initial function value:", f_numpy(start_point))
print("Initial gradient:", numerical_gradient(f_numpy, start_point))

# Run gradient descent
final_point, history = gradient_descent(f_numpy, start_point, learning_rate=0.1, num_steps=50)

print("\nFinal point:", np.round(final_point, 6))
print("Final function value:", f_numpy(final_point))
print("Final gradient:", numerical_gradient(f_numpy, final_point))

# Visualization: Quadratic Function f(x,y) = x² + y²
print("\nVisualizing Quadratic Function f(x,y) = x² + y²")
f_symbolic = x**2 + y**2
start_points = [np.array([4.0, 3.0]), np.array([-3.0, 4.0]), np.array([2.0, -4.0])]
x_range = (-5, 5)
y_range = (-5, 5)
num_points = 100

# Create meshgrid
x_vals = np.linspace(x_range[0], x_range[1], num_points)
y_vals = np.linspace(y_range[0], y_range[1], num_points)
X, Y = np.meshgrid(x_vals, y_vals)

# Evaluate function
f_vec = np.vectorize(lambda x, y: f_numpy(np.array([x, y])))
Z = f_vec(X, Y)

# Create figure with subplots
fig = plt.figure(figsize=(15, 5))

# 3D Surface plot
ax1 = fig.add_subplot(131, projection='3d')
surf = ax1.plot_surface(X, Y, Z, cmap='viridis', alpha=0.8, edgecolor='none')
ax1.set_xlabel('x')
ax1.set_ylabel('y')
ax1.set_zlabel('f(x,y)')
ax1.set_title('3D Surface with Gradient Descent Paths')

# Find and plot stationary points
x_sym, y_sym = sp.symbols('x y')
gradient_sym = [sp.diff(f_symbolic, x_sym), sp.diff(f_symbolic, y_sym)]
stationary_pts = sp.solve(gradient_sym, (x_sym, y_sym), dict=True)

for pt in stationary_pts:
    if all(val.is_real for val in pt.values()):
        x_val = float(pt[x_sym])
        y_val = float(pt[y_sym])
        z_val = f_numpy(np.array([x_val, y_val]))
        ax1.scatter([x_val], [y_val], [z_val], color='red', s=100, marker='*')

# Gradient descent trajectories
for start in start_points:
    _, history = gradient_descent(f_numpy, start, learning_rate=0.1, num_steps=50)
    history = np.array(history)
    xs = history[:, 0]
    ys = history[:, 1]
    zs = np.array([f_numpy(np.array([x, y])) for x, y in zip(xs, ys)])
    ax1.plot(xs, ys, zs, 'r-', linewidth=2, alpha=0.8)
    ax1.scatter(xs[0], ys[0], zs[0], color='green', s=50, marker='o')

# Contour plot
ax2 = fig.add_subplot(132)
contours = ax2.contour(X, Y, Z, levels=20, cmap='viridis')
ax2.clabel(contours, inline=True, fontsize=8)
ax2.set_xlabel('x')
ax2.set_ylabel('y')
ax2.set_title('Contour Plot with Gradient Descent Paths')

# Plot stationary points
for pt in stationary_pts:
    if all(val.is_real for val in pt.values()):
        x_val = float(pt[x_sym])
        y_val = float(pt[y_sym])
        ax2.plot(x_val, y_val, 'r*', markersize=15, label='Stationary Point')

# Plot gradient descent paths
for i, start in enumerate(start_points):
    _, history = gradient_descent(f_numpy, start, learning_rate=0.1, num_steps=50)
    history = np.array(history)
    ax2.plot(history[:, 0], history[:, 1], 'r-', alpha=0.8)
    ax2.plot(history[0, 0], history[0, 1], 'go', markersize=8)
    ax2.plot(history[-1, 0], history[-1, 1], 'ro', markersize=8)

# Gradient vector field
ax3 = fig.add_subplot(133)

# Sample gradient at fewer points for clarity
x_grad = np.linspace(x_range[0], x_range[1], 20)
y_grad = np.linspace(y_range[0], y_range[1], 20)
X_grad, Y_grad = np.meshgrid(x_grad, y_grad)

# Compute gradients
U = np.zeros_like(X_grad)
V = np.zeros_like(Y_grad)
for i in range(len(x_grad)):
    for j in range(len(y_grad)):
        grad = numerical_gradient(f_numpy, np.array([X_grad[j,i], Y_grad[j,i]]))
        U[j,i] = -grad[0]  # Negative for descent direction
        V[j,i] = -grad[1]

# Normalize for better visualization
N = np.sqrt(U**2 + V**2)
U_norm = U / (N + 1e-10)
V_norm = V / (N + 1e-10)

ax3.quiver(X_grad, Y_grad, U_norm, V_norm, N, cmap='coolwarm', alpha=0.8)
ax3.contour(X, Y, Z, levels=10, colors='gray', alpha=0.3)
ax3.set_xlabel('x')
ax3.set_ylabel('y')
ax3.set_title('Gradient Descent Direction Field')

plt.tight_layout()
plt.show()

Output:

Starting point: [10. 10.]
Initial function value: 200.0
Initial gradient: [20. 20.]

Final point: [0.000143 0.000143]
Final function value: 4.0740719526791846e-08
Final gradient: [0.00028545 0.00028545]

Visualizing Quadratic Function f(x,y) = x² + y²

Gradient Descent Visualization

Constrained Optimization: Lagrange Multipliers

Real optimization problems are rarely unconstrained. The method of Lagrange multipliers transforms these constrained problems into a form we can solve systematically.

Imagine you’re hiking along a mountain ridge trail (your constraint curve $g(x) = 0$). The mountain has contour lines—curves of constant elevation. At the highest point you can reach while staying on the trail, something special happens: the trail is tangent to a contour line.

Think about it: if the trail crossed through the contour line at an angle, you could walk along the trail to reach a higher contour. Only when the trail is perfectly tangent to a contour line—touching it at exactly one point—have you found the highest elevation on that trail.

Now here’s where the gradients come in:

The gradient $\nabla f$ points perpendicular to the contour lines (pointing uphill, in the direction of steepest ascent)
The gradient $\nabla g$ points perpendicular to the constraint curve (the trail)
When the contour line and trail are tangent to each other, their perpendiculars must be parallel

This is why $\nabla f = \lambda \nabla g$ at the optimum.

The Lagrangian Method

For a problem with multiple constraints:

$$x^* = \arg\min_{x \in \mathbb{R}^n} f(x) \quad \text{s.t.} \quad g_i(x) = 0, \quad i = 1, …, m$$

We construct the Lagrangian function: $$\mathcal{L}(x, \lambda) = f(x) + \sum_{i=1}^m \lambda_i g_i(x)$$

The optimality conditions are simply: $$\nabla_x \mathcal{L} = 0 \quad \text{(gradient condition)}, \quad \nabla_\lambda \mathcal{L} = 0 \quad \text{(recovers constraints)}$$

This transforms our constrained problem into solving a system of equations—much more tractable computationally.

Inequality Constraints: Karush-Kuhn-Tucker Conditions

When constraints can be inequalities:

$$x^* = \arg\min_{x \in \mathbb{R}^n} f(x) \quad \text{s.t.} \quad g_i(x) = 0, \quad h_j(x) \leq 0$$

We augment the Lagrangian: $$\mathcal{L}(x, \lambda, \mu) = f(x) + \sum_i \lambda_i g_i(x) + \sum_j \mu_j h_j(x)$$

The key difference with inequalities:

An inequality constraint $h(x) \leq 0$ might be:

Active: $h(x) = 0$ (you’re at the limit)
Inactive: $h(x) < 0$ (you have slack)

The KKT conditions encode this:

Complementary slackness: $\mu_j h_j(x) = 0$
- If constraint is active ($h_j = 0$), then $\mu_j$ can be positive
- If constraint has slack ($h_j < 0$), then $\mu_j = 0$
- Result: At the optimum, $\sum_j \mu_j h_j(x^*) = 0$ always!
- But the individual $\mu_j$ values tell us which constraints matter
Non-negativity: $\mu_j \geq 0$
- Tightening a constraint can only make things worse (or same), never better
- So the sensitivity must be non-negative

Intuition: The Lagrangian “penalizes” constraint violations during optimization. At the solution, complementary slackness ensures no penalty remains, but the multipliers $\mu_j$ reveal which constraints are binding (positive $\mu$) versus irrelevant (zero $\mu$).

Example: Minimize cost subject to production $\geq$ demand:

If you’re producing exactly the demand: constraint active, $\mu > 0$
If you’re overproducing anyway: constraint inactive, $\mu = 0$

Economic Interpretation

The multiplier $\lambda_i$ has a concrete meaning (for a constraint $g_i(x) = b_i$): $$\lambda_i = -\frac{\partial f^*}{\partial b_i}$$

It’s the shadow price—how much the optimal value improves per unit relaxation of constraint $i$. In economics:

Budget constraint: $\lambda$ = marginal utility of income
Resource constraint: $\lambda$ = marginal value of that resource
Production quota: $\lambda$ = marginal cost of production

This duality between optimization and valuation is fundamental to economic theory and pricing mechanisms.

Practical Implementation

Modern solvers handle the mechanics, but understanding helps diagnose issues:

Multiple solutions: Check second-order conditions (bordered Hessian)
No solution: Constraints may be inconsistent
Slow convergence: Problem may be ill-conditioned
Large multipliers: Constraint is very restrictive, consider reformulation

Note on Sufficiency

The KKT conditions are necessary for optimality. For sufficiency, check:

Convex objective function (for minimization)
Convex feasible region
Or verify second-order conditions (bordered Hessian)
